供应直线导轨 滚珠丝杠 重型滑轨

1. FX3076 Extra Heavy Duty Full Extension SlideApplications: Heavy duty storage drawers, truck bodies, and large pantry pull-outs etc.Feature: Can be pushed and pulled more than 100, 000 timesFinish: Electro-zinc plated with clearorcolor chromate.Length: 8"-60 ".Height: 76.36mmSide space: 19.1±0.7mmLoad capacity: 500lbs (227kg)/ 18"Material：Work hardened cold rolled steel (2.5mm*2.2mm*2.5mm).FX3076三节全展超重型钢珠滑轨系列应用：高承载的活动柜，工业用柜，食品柜，货柜，自动售货机，自动取款机，消防车，救防车，多用途运载车，仓储设备机柜等要求全展开的用途特点：可以抽拉10万次表面处理: 镀蓝锌，彩锌，可采用环保电镀长度：8 ''-60 ''高度：76.36mm厚度：19.1±0.7mm承重：500磅（227公斤）/18"承载：长度超出24", 承载力每增加2"下降15-20KG之间材质：冷轧钢。（2.5*2.2*2.5）2. FX3076L Extra Heavy Duty Slide with Lock-in/Lock-out FunctionApplications: Telecommunication racks, Server cabinets, ATM etc.Feature: Lock-in/lock-out functions, can be pushed and pulledmore than 100, 000 timesFinish: Electro-zinc plated with clearorcolor chromate.Length: 8"-40"Height: 76.36mmSide space: 19.1±0.7mmLoad capacity: 500lbs (227kg)/pair (24")Material: Work hardened cold rolled steel.FX3076L三节全展超重型钢珠滑轨系列应用：高承载的活动柜，工业用柜，食品柜，货柜，自动售货机，自动取款机，消防车，救防车，多用途运载车，仓储设备机柜等要求全展开的用途。特点：双重自锁,拉出来锁住，退回去锁住。表面：镀蓝锌、彩锌长度：8''-40 ''高度：76.36mm厚度：19.1±0.7mm材料：冷轧钢。加图片，加图纸，
